30M Width Aluminum Frame with White PVC Cover Big Exhibition Tents for Outdoor Tradeshow Exhibition
UNIVERSAL TENT is an experienced tent supplier with creative and delicate solution in tent field. We focus on global PVC tents market and requirements and supply satisfactory and customized solution to our customers.
Description:
It's a very economical and elegant A shape tent, which often used for outdoor exhibition, trade show, wedding, party and many other events. The clear span of this type tent is from 3m to 50m and the length is no limited which can fit different requirements. With no pole inside, it’s 100% used for the events. Easy to be assembled and dismantled. It's the most suitable tent type for your tent rental business and event business. Also our exhibition tent can have customized printing logo on the roofing and sidewalls, which is impressed every guest.
Size of our Tent:
The clear-span of tent is from 3m to 40m, the length could be 6m, 9m, 12m, +3m more or 10m, 15m, 20m, and +5m more. And the length of our tent is no limited. Customized size can also be available.
| Clear Span | Bay Distance | Eave height | Ridge height | Main profile |
| 10m/32.81' | 5m/16.4' | 3.88m | 5.53m | 204x110x4mm(4-channel) |
| 12m/39.37' | 5m/16.4' | 3.88m | 5.83m | 204x110x4mm(4-channel) |
| 15m/49.21' | 5m/16.4' | 3.88m | 6.3m | 204x110x4mm(4-channel) |
| 20m/65.62' | 5m/16.4' | 3.88m | 7.1m | 204x110x4mm(4-channel) |
| 21m/68.90' | 5m/16.4' | 3.88m | 7.5m | 204x110x4mm(4-channel) |
| 25m/82.02' | 5m/16.4' | 3.88m | 7.88m | 204x110x4mm(4-channel) |
| customized | customized | customized | customized | customized |
| The length can be extended by 5m bay such as 15m,20m,30m,40m...Customized size or shape is available. |
Applications:
Widely used for parties, weddings, events, celebrations, sports, trade shows, warehouse, Hajj, conferences, cafe shops, restaurants, corporate events, etc.
Accessories:
Tent Covers: different colors for your choose, transparent cover
Side Windows: arch or square clear PVC windows, mesh window, glass window
Wooden Flooring System: VIP cassette flooring, simple cassette flooring
Doors: double-wing glass door, single-wing glass door, glass fire door, aluminum door, rolling shutter(automatic or manual)
Side Walls: soft PVC fabric wall, glass solid wall, ABS hard wall, sandwich panel wall, steel plate wall
Interior decoration: roof lining, side curtains, different colors and designs are available
Fixing Methods: steel pegs, weight plate, expandable bolts
Rain Gutters: inner roof beam rain gutter or rain gutter between two similar tents
Optional Items: table, chair, lighting, AC, carpet, installation tools, booth, mobile toilet, etc.
Specification of our Tent:
Fabric: Double PVC coated polyester fabric, 750-900g/sq. M, water proof, UV resistance, fire retardant according to standard NFPA701, CFM & DIN4102 B1/M2.
Frame: Hard pressed extruded aluminum 6061/T6, anodized surface finishing.
Connections: Hot-DIP galvanized.
Main frame profile size: 204X120X4mm.
Wind load: 70-100km/h.
